Wall Mount Soundproof Sliding Movable Mirror Partition Wall In office Partitions
BUNGE partition wall description
Movable partitions are a series of individually operated panels along a track system designed for maximum space planning flexibility. They can be arranged quickly, easily and efficiently.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door |
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized)
|
Features:
1> Movable partition is modernized decoration style. It can separate the space speedly and
conveniently. And it has sound insulation and heat insulation and fireproof function;
2> The Partition Board is made from high density s/s frame, special made rubber, excellent sound
insulation cotton and finish board etc. the finish board is flat and hard;
3> The finish board is inserted in the aluminum track, assembled with multi direction wheels; the
board can be stored in may different ways;
4> It doesn’t need track on the floor, we only hang the track on the ceilings and it can be at the
same plane with the ceiling decoration. It won’t affect the whole decoration style;
5> Around the board ,there is sound insulation rubber, it can help to insulate the sound entering;
6> The operation ways is much easier, it’s better than the old ways which was use spring before;
7> We can add single or double doors on the board for convenience;
8> We have many different finish to meet customer different requirement and get different decoration effect.
Application:
The movable partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant,schools,office,religion,hospitals,shopping arcades and many other indoor applications product.
