Collapsible Office Acoustic Folding Movable Partition Wall Customized Color
Collapsible movable partition walls features
Individual panels that can be stored away for maximum space utilization.
Operable top and bottom seals for effortless operation.
Isolated aluminium frame construction for enhanced acoustics.
High performance multiple in fill's for maximum sound attenuation.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
No floor track ensuring obstruction free threshold.
Three panel sizes to accommodate a wide range of acoustic requirements .
Extensive range of surface finishes can be applied.
Technical information
| Model | BG-65 series | BG-85 series | BG-100 series |
| Suspension system | Aluminum hanging | Aluminum hanging | Aluminum hanging |
| Basic thickness | 65mm | 85mm | 100mm |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm |
| Max height | Up to 3800mm | Up to 4500mm | Up to 6500mm |
| Width | 600-1230mm | 600-1230mm | 800-1230mm |
| Floor/ceiling sealing strength | Telescopic aluminum tube with rubber strip |
| Side walls sealing strength | Double seal tape |
| Sound insulation level | 26dB-30dB | 28dB-34dB | 32-40dB |
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
Collapsible movable partition walls details
1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.
2- Top supported without floor track or guide, only have track on the ceiling.
3- Clear anodized extruded aluminum tracks and frames,customized powder coated color are available.
4- Sound insulation certificate :STC 32db to 52db, ASTM standard of acoustic tested in HongKong.
5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.
6- Fast delivery and Rich experiences in oversea project installation guide & supervision.
