Durable Acoustic Room Dividers , Banquet Hall Sound Proofing Partitions

Brand Name : BANGE

Model Number : 85 mm acoustic room dividers

Certification : ISO9001

Place of Origin : Guangdong

MOQ : 10 square meters

Price : US Dollars 80 - 120 per square meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 square meters per month

Delivery Time : 15-20 days

Packaging Details : Carton package, MDF batten on four section sides , foam board on both front face.

Open style : sliding

Product name : Acoustic room dividers

Feature : Sound proofing

Size : 85 mm

Color : Accept customized

Application : Banquet hall,office,function room

Panel width : 500 mm--1230 mm

Door material : Melamine board

Surface : Melamine,leather,fabric,plywood

Position : Interior

Width : 85 mm(3 1/4 inch)

Contact Now

Banquet Hall Sound Proofing Partitions Acoustic Conference Room Dividers

Details of Acoustic Room Dividers

1) When moving a acoustic room dividers wall panel, there is a 20-25mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.

2) Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.

3) The pressure seals are extend and retracted by a single 180 degree turn of removable operating handle.

4) Final Closure of the wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.

5)In their stacked position, the panel form compact package and can be accommodated in the smallest of spaces depending on the room situation. The low weight of the panel and the associated structural advantages are particularly noticeable here. The standard stack or parkingtrack systems offer convenient operability with a minimum of noise from the individual panels as they slide into position.

Durable Acoustic Room Dividers , Banquet Hall Sound Proofing Partitions

Specifications of Sound Proof Partitions System

Model

BG-65 series

BG-85 series

BG-100 series

BG-high series

Suspension system

Aluminum hanging

Aluminum hanging

Aluminum hanging

Steel hanging

Basic thickness

65mm

85mm

100mm

100mm

Total thickness

65/75/85/95mm

80/90/100/110mm

100/120/130mm

100/120/130mm

Max height

Up to 3800mm

Up to 4500mm

Up to 6500mm

Up to 12000mm

Width

600-1230mm

600-1230mm

800-1230mm

800-1230mm

Floor/ceiling sealing strength

Telescopic aluminum tube with rubber strip

Side walls sealing strength

Double seal tape

Sound insulation level

26dB-30dB

28dB-34dB

32-40dB

32-48dB

Panel structure

Aluminum frame with wooden keel

Aluminum frame with steel keel

Panel density

22-28kg/sqm.

24-32kg/sqm.

32-50kg/sqm.

/

Surface material

Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

Durable Acoustic Room Dividers , Banquet Hall Sound Proofing Partitions

Features of Acoustic Room Dividers

1.Hanging on ceiling.The floor without a track, just put the rail mounted on the ceiling.

2.Excellent Quality.Each pieces of partition can turn around 360 degree.

3.Stable and secure.After partition is stable and reliable, and is not easy to swing.

4.Energy efficient.The large space divided into a small space, in order to reduce air conditioning power consumption;

5.Heatproof&fireproof.Good heat insulation performance,Adopt effective fire prevention materials.

6.Elegant appearance.Surface any adornment, can unite with indoor adornment effect.

7.Easy to collect.Can be hidden in the special coffer, does not affect the overall appearance.

8.Various applications.Hotels,exhubition halls,restaurants,multi-functional rooms etc.

Durable Acoustic Room Dividers , Banquet Hall Sound Proofing Partitions
