Divide Space Top Hanging System Soundproof Room Divider Hotel Acoustic Folding Partition Wall
Specification:
The basic production material of acoustic wall partition is mdf board panel and soundproof rock wool, so it has a good sound-absorbing effect, which is what most customers pursue, because everyone likes to live and work in a quiet environment, and use the activity partition as a segmentation.
The acoustic partition wall can satisfy this problem. Different employees of the company need to work in different environments and the activities can solve this problem. It can effectively divide and make the space look more complete, which is the first choice for the company's decoration.
Feature:
1. Efficient fire prevention: the material of the movable partition is made of fireproof material and has good fireproof performance;
2.Heat insulation: according to different occupancy rates, the space can be divided into small spaces, and good thermal insulation performance;
3.Sound insulation and environmental protection: its sound insulation coefficient can reach 53dB, sound insulation effect is good;
4.Stable and safe: stable and reliable, not easy to swing, shake;
5.No rail suspension: no need to install the ground rail on the floor, its track is installed on the ceiling.
Acoustic partition wall application:
Acoustic wall partition has good sound absorbing effect and fireproof effect. It can be used in different occasions. It can be used in the meeting of the company. It is very effective to use the movable partition in some densely populated restaurants. The surface of the movable partition is very Smooth, it is very convenient to wipe when needed.
Acoustic wall partition belongs to the products in the partition series, and is widely used in high-end places such as hotels, hotels, schools, business clubs, exhibition centers, etc. Therefore, the beauty and quality of the screens of the activities are the first choice for VIP customers, and the planning of the scheme should pay more attention to the overall situation. The overall look is more atmospheric and luxurious. We pay more attention to customer perception, fully consider customer needs, and provide you with a more perfect experience.
Technical information:
| TYPE | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only |
| Track system | Single or twin point |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500 - 1200mm 1' 5/8" -- 4' | 500 - 1200mm 1' 5/8" -- 4' | 500 - 1200mm 1' 5/8" -- 4' |
| Frame | Aluminum | Aluminum | Aluminum |
| Surface material | 9mm | 9mm | 12mm |
| Fire safety | Optional class I | Optional class I | Optional class I |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
| Locking | Optional lock to passing doors |
| Passing doors | Single open in one panel or double open in two panel |
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Acoustic partition wall structure:
To create a better sound insulation folding partition wall door, we put high density fiberglass inside the partition frame, Sourcing from imported world famous fiberglass brand Owens Corning which is the best sound insulation cotton manufacturer.
We can offer:
1. Profession--We have professional sales staff. Any questions will be replied within 24 hours.
2. Price--Because we are factory , so we can provide higher quality and lower price products.
3 . Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.
4. Team--We have our own engineering department, according to your request for your tailor-made for your product.
