Aluminium Door Track System Acoustic Wall Partitions Movable Sliding Partition Walls
Technical Information:
| Model | BG65 Series | BG80 Series | BG100 Series | BG High-Series |
| Suspensionsystem | Aluminum hanging | Steal Hanging |
| Basic Thickness | 65 mm | 80 mm | 100 mm | 100 mm |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. |
| Side walls sealing strength | Double seal tape |
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel |
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized |
Sliding Partition Walls Features
1. Large selection of standard finish treatment.
2. It can quickly and easily separate the space.
3. Retractable top and bottom seals allow easy movement.
4. Quick divide by simple pull / latch operation.
5. No floor track is needed for sliding partition walls for rooms.
6. Tight vertical seal prevents sound leakage and helps align the panel during installation.
7. Sliding office partition walls are a modern decorative style with noise insulation, heat insulation, and fireproofing function.
Sliding Partition Walls Application
Sliding partition wall is a range of acoustically high-performance and beautiful divider for creating the most flexible space in offices,conference room, schools, colleges, churches, hotel meetings, restaurants, shops, hotels, inspection centers, multi-function rooms, stations, clubs, art centers, stadiums, sports centers, art museums, the court, convention centers, golf clubs, and functional suites.
With high levels of sound attenuation and custom parking, office partition walls in room provides a range of solutions for even the most complex requirements.
Finishes of Movable Partition Walls
-
❶ Wooden (MDF, Plywood bare raw finish) & (Melamine, Veneer)
-
❷ Fabric (fabric with mdf board hard covers) & (fabric with sponge soft covers)
-
❸ Leather (leather with mdf hard covers) & (leather with sponge soft covers)
-
❹ Wallpaper, Vinyl, Fireproof board
-
❺ Acoustic panels
-
❻ Tempered glass. etc.
Externally, most movable partition wall panels look the same, but it’s not simply the outside which makes a good movable wall, it is what’s inside the panel which makes the difference.
