Fabric Surface Mdf Board Acoustic Wooden Folding Partition Wall Panels For Office

Guangdong Bunge Building Material Industrial Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Fabric Surface Mdf Board Acoustic Wooden Folding Partition Wall Panels For Office

Brand Name : BUNGE

Model Number : Series 85 mm folding partition walls

Certification : ISO9001

Place of Origin : China,Guangzhou

MOQ : 10 square meters

Price : 91 / 135 dollar per square meter

Payment Terms : D/A, D/P, L/C, T/T, Western Union, MoneyGram

Supply Ability : 5000 square meters per month

Delivery Time : Shipped in 10 days after payment, based on the quantity.

Packaging Details : Carton package, MDF batten on four section sides ,foam board on both front face.

Product name : Folding partition walls

Application : Office,classroom

Thickness : 85 mm

Height : Less than 6 m

Surface : Mdf melamine,plywood,MDF bare finish

Color : Multi color

Contact Now

Fabric Surface Sliding Aluminium Track Mdf Board Acoustic Office Wood Folding Partition Wall Panels

Specification:

The folding partition wall is a set of soundproof walls composed of every single partition. Each piece is equipped with two horizontal hanging wheels or single wheel. It depends on the horizontal hanging wheel to make the hanging travel along the track. It can make a 360 degree right angle turn and travel freely.

Promote to other space collections, according to different space use needs, separated by multiple independent small space. The vertical contact points of each single piece partition are connected by concave and convex positions. The sealant strips are embedded and the upper and lower tops are equipped with a retractable soundproof seal mechanism.

Feature:

Top hanging system without floor track, no need floor track.

From ceiling to finished floor folding partition wall.

Good soundproof feature that panels are included soundproof rock wool or soundproof felt.

Sliding and folding,when don't need to divide space, can be parking in one area.


Surface is custom designed, mainly melamine, fabric,leather ,Mdf bare finish,plywood and etc.

Fabric Surface Mdf Board Acoustic Wooden Folding Partition Wall Panels For Office

Application:

Folding partition wall is mainly using in multi function hall,banquet hall,laboratory,classroom,conference room,gymnasium,convention hall, kindergarten,art gallery,restuarant,meeting room,ballroom and etc.

Technical information:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Fabric Surface Mdf Board Acoustic Wooden Folding Partition Wall Panels For Office

Advantage:

Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.


Cost savings: installation does not affect the construction of smallpox and the ground.


Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.


Easy combination: in the re-assembly can make full use of building materials.


Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.

Our service:

We design and manufacture value for money products with a one year warranty on all the outstanding ranges illustrated in this brochure.


We offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
